High-Efficiency SMPS Board for Audio Systems with Peak Current Limitation
By:Admin
The 3e Audio Cycle SMPS is a great example of this. It features cycle peak current limitation, which is designed to improve efficiency and reduce the noise produced by the power supply. It also features low standby power, which means that it consumes relatively little power when not in use.
One of the standout features of the 3e Audio Cycle SMPS is its compact size. Measuring just 105mm x 100mm x 35mm (L x W x H), this power supply is small enough to fit into a wide range of audio equipment.
Another great feature of this SMPS is its additional AUX VCC output. This 12V/0.5A output is designed to power other devices and components in your audio system, such as pre-amplifiers, DSPs, and more.
When it comes to setting up the 3e Audio Cycle SMPS, it is important to understand the high voltage and low voltage sides of the board. The AC IN is the high voltage input, ranging from 100V to 220V, which is connected to an AC line socket. The PVDD output is the main output for the power amplifier board. Finally, the AUX VCC output is the auxiliary output for other applications.
Overall, the 3e Audio Cycle SMPS is a great choice for anyone looking for a compact, efficient, and reliable power supply for their audio equipment. Its cycle peak current limitation, low standby power, and additional AUX VCC output make it a standout option in the market.
In summary, the 3e Audio Cycle SMPS is an excellent option for those in need of a 12V 5A power supply. Its compact size, efficient design, and additional AUX VCC output make it an attractive option for a wide range of audio equipment. If you are looking for an SMPS for your audio system, the 3e Audio Cycle SMPS is definitely worth considering.
